M.C.C. ATTENDANTREARCONSOLE
-
Toaccess all components and switches located in theM.C.C. area, remove the
screws that secure theaccess panel located in the left sideElectrical Control
Compartment (fig. 7)
- Nowall switchwiring, backlightingandother electrical components, alongwith the
oxygen lines, outlets and connections areeasily accessed for inspectionand service. (fig.
8)
Fig. 7
Fig. 8
OILPRESSURESWITCH
The oil pressure switchwhich operates theHOURMETER and theAMBULANCE
CONNECTFUNCTIONS is locatedabove theengineoil filter on the lower left sideof the engine.
(fig. 9)
please refer to theelectrical schematicsonwhat thepressureswitchcontrols
Fig. 9
