RECT–79H13–C
RECT–79H26–C
RECT–79BZ
TheRECT–79H13–C 13°Tilt DownScene Light and theRECT–79H26–C 26°Tilt DownScene Light
aremolded fromLexan
®
andhavebeendesigned to fit all popular emergency vehicles.Theyeachuse
two replaceable GE #890 automotive 12V halogen lamps rated at 27 watts each. These lamps are
furnished with drill template, gasket, and mounting hardware. Watertight lamp connectors are
optional.
ORDERING INFORMATION
SIZE
PHOTOMETRICDATA
Model No.
Description
Lamp
RECT–79H13–C Clear 7" x 9" 13°
Halogen
Tilt DownScene
Light
RECT–79H26–C Clear 7" x 9" 26°
Halogen
Tilt DownScene
Light
Accessories
RECT–79BZ
ChromePlated Lexan
®
Recessed
Mount Fixture
890
27Watt, 12VDCHalogen Lamp
890–24
27Watt, 24VDCHalogen Lamp
890HP
37Watt, 12VDCHalogen Lamp
890–CONN
Watertight Connector For Lamp
889
27Watt, 12VDCHalogen Lampwith 90°
AngledSocket Base
Clear lens, 2–890 lamps at 12.8V
13°OpticalTilt
26°OpticalTilt
Vertical Distributions
IntensityAt H–V
0
30
60
90
120
150
180
0
30
60
90
120
150
180
Mounting hole pattern
(4) – #8 screws on
7–1/4" x 5–1/4" centers
7–1/8"
1"
2"
Mounting
Plane
9-1/8"
Front
View
Side
View
Intensity inCandelas
Lighthead
Clear Angle
RECT–79H13–C 3400 13° BelowHorizontal Plane
RECT–79H26–C 1700 26° BelowHorizontal Plane
RECT–79H26–C
Mounted inRECT–79BZ
RECT–79H13&–79H26DEGREETILTDOWNSCENELIGHTS
12VHalogen Lamps
2100WESTOBISPO
GILBERT, AZ. 85233
PHONE: 800–338–3133
FAX:
800–688–6627
®
