ORDERING INFORMATION
Model No.
Description
RECT–37S–A
Amber 3" x 7" Strobe Lamp
RECT–37S–A/B
Amber/Blue 3" x 7" Strobe Lamp
RECT–37S–A/C Amber/Clear 3" x 7" Strobe Lamp
RECT–37S–B
Blue 3" x 7" Strobe Lamp
RECT–37S–B/C Blue/Clear 3" x 7" Strobe Lamp
RECT–37S–C
Clear 3" x 7" Strobe Lamp
RECT–37S–R
Red 3" x 7" Strobe Lamp
RECT–37S–R/A
Red/Amber 3" x 7" Strobe Lamp
RECT–37S–R/B
Red/Blue 3" x 7" Strobe Lamp
RECT–37S–R/C Red/Clear 3" x 7" Strobe Lamp
Accessories
RECT–37–BMFA–BK Bumpermount, black Lexan
®
RECT–37–BMF–W Bumpermount, cast aluminum, wheel abraded
RECT–37–BMF2
Bumpermount, cast aluminum, polished
RECT–37–SMF
Surfacemount, cast aluminum
RECT–37–DSMF Deep surfacemount (no cut into vehicle)
(see pageE9)
RECT–37–FMF
Recessedmount fixture (see pageE10)
RECT–37–15–DEG 15Deg. mount, angles light down (see pageE11)
RECT–37–TSMF
15Degreemount, angles forward (see pageE11)
RECT–37–TSMF–P
Passenger’s side intersection bezel for ’92–FORDE350
RECT–37–TSMF–D
Driver’s side intersection bezel for ’92–FORDE350
The RECT–37S sealed beam strobe lamp is 100% watertight and features a quartz coated reflector. It is
molded from Lexan
®
and has been designed to fit all popular emergency vehicles. The RECT–37S has been
designed tomeet Federal Ambulance Specification KKK–A–1822Cwhen used with the proper TOMAR strobe
power supply. The unit will fit into the Siren Strobe™ grill mounted speaker and warning light fixtures. The
RECT–37S is furnished with drill template, gasket, and mounting hardware; and it is usable with all TOMAR
power supplies.
SIZE
PHOTOMETRICDATA
Clear LampCover, 770Power Supply operating in the hi-powermode
Vertical Distribution
Polar Distribution
Vertical beamwidth@ 1/2 intensity point = 10°
Polar beamwidth@ 1/2 intensity point = 90°
IntensityAt H–V
(Candelas effective, based on a single
head. Divide by 2when using 2 heads
that flash simultaneously. Intensities
shown in “normal mode”).
Power
INTENSITY INCANDELASEFFECTIVE
Supply
CLEAR AMBER BLUE RED
772–1228 6620
5630 3320 1620
770–1228 10500
8480 4920 2340
776–1228 10500
8480 4920 2340
782–1228 12760
10300 6110 2680
780–1228 12760
10300 6110 2680
0
30
60
90
120
150
180
0
30
60
90
120
150
180
3"
1-1/16"
1-1/2"
7-1/4"
Front
View
Side
View
Mounting
Plane
Mounting hole pattern (4) – #8 screws on 6-9/16" X 2-3/8" centers
RECT–37S–A/B
RECT–37S–C
RECT–37S–R
RECT–37S–B
RECT–37–BMF2
RECT–37–SMF
HERMETICALLY
SEALED
100%WATERTIGHT
RECT–37S3"X7"SEALEDBEAMLIGHTHEAD
Single Strobe,
54Watt Power Rating
RECT–37–BMFA–BK
2100WESTOBISPO
GILBERT, AZ. 85233
PHONE: 800–338–3133
FAX:
800–688–6627
®
