STRYKER BATTERY
CHARGER INSTALATION
September 26,
2017
Page 1 OF 1
AMBULANCE TYPE:
DEMERS 63000 AND UP
UNITS AFFECTED:
ALL UNITS EQUIPPED WITH THE STRYKER POWERPRO
STRETCHER
ACTION: INSTALLATION OF THE STRYKER POWERPRO BATTERY CHARGER
LABOUR TIME:
.
3 HRS
BILL TO: BCAS
SERVICE PROCEDURE:
1. Charger is to be mounted in the Monitor
compartment on the right side of patient
compartment.
2. Position the mounting base 1 inch from the
front edge and 1/2 inch from the top shelf as
shown.
3. Using the charger base guide pins as a
template, drill two 1/8” holes.
4. Squeeze two ¼” beads of silicone on to the base
bottom and install to the wall with the supplied
self-tapping screws.
5. Insert the power cord and mount the charger
onto the base. Stick the double sided tape to the
transformer and attach to the wall behind the
charger. Secure the excess cables with zip ties.
1/2”
1”
GUIDE PINS
