Schematic Index
DRAWING# DESCRIPTION Page #
Electrical Information
Power DoorLocksWith RemoteKey-lessEntrySchematic 501056R04 83-
Pre-Wired2-WayRadio and CellularSchematic 501367R00 93-
3-WayStrobe Schematic 501369R01 10 3-
12Volt DCPower -Dual Incubator Dual OutletsLaerdal Schematic 501373R01 11 3-
SVPSA-500-06Siren Schematic 501374R01 12 3-
Park Signal Brace Lights Schematic 501378R01 13 3-
Console andMCCSpare SwitchSchematic 501381R01 14 3-
Console andMCCBackLighting Schematic 501383R01 15 3-
Dual AlternatorWithSurePower Isolator Schematic 501384R01 16 3-
JetcoFog/Driving-Light Schematic 501386R01 17 3-
RicoElectric SuctionSchematic 501390R01 18 3-
AudioAdjust Schematic 501396R01 19 3-
CavatronOutlet Schematic 501397R01 20 3-
Park -Brake -Lights Schematic 502013R00 21 3-
110Volt Shoreline Schematic 502014R00 22 3-
Wig-WagSchematic 502015R00 23 3-
Park Brake Set Light Schematic 502016R00 24 3-
Park -Signal Lights Schematic 502017R00 25 3-
Back-UpAlarmWith 60Second DelayMomentaryDisableSwitchSch 502018R00 26 3-
Anti-Theft Schematic 502019R00 27 3-
Heater -Air ConditioningSchematic 502020R00 28 3-
Power VentilationWithExhaust Vent Schematic 502021R00 29 3-
Right Cot-Light Schematic 502022R00 30 3-
Left Cot-Light Schematic 502023R00 31 3-
DoorAjar Light Schematic 502024R00 32 3-
Side SceneLights Schematic 502026R00 33 3-
3250 Flasher PatternSchematic 502099R00 34 3-
ConsoleGooseneckLight Schematic 502101R00 35 3-
MCCLight Schematic 502102R00 36 3-
