Electrical Information
Vehicle
Page 3-4
Crestline
Manual
2/3/2004
Coach
General Notes
ContinuouslyPowerCircuits andComponents
With the vehicle having a dedicated conversion battery system, there are components that have power
to them all the time. Below is a list of these components. For more information on these see their
related schematicsby referencing the schematics index in this section.
Anti-theft System, 12 volt Outlets, Two-wayRadio, Incubator Outlets,MCC light, Fluorescent Lights
(not on all vehicles), ClearanceLights, PowerDoor locks, Heart Interface Inverter, EmergencyBattery
Boost (not onall vehicles).
Inverter
The110-volt inverter is in theECCCompartment.
For further informationon the inverter, see theOEM sectionof thismanual.
ElectricalConnectorCodes
The following tables areprovided to assist you in the trouble shootingof electrical problems should they
occur. If you need to call Crestlinewith an electrical question, pleasehave this informationavailableas
the Service and Warranty Technician will make frequent references to these tables and the
accompanyingdrawings.
