Connector Index
DRAWING # LOCATION Connector PINS
Electrical Information
ECCBoard 502494R00 C401 12
ECCBoard 503652R01 12
ECCBoard 502403R01 C402 12
ECCBoard 502494R00 12
ECCBoard 503652R01 12
ECCBoard 502244R00 C403 12
ECCBoard 502251R00 12
ECCBoard 502266R00 12
ECCBoard 502844R00 12
ECCBoard 504154R00 C404 12
ECCBoard 502340R00 C405 12
ECCBoard 502496R01 12
ECCBoard 504155R00 12
ECCBoard 502266R00 C406 12
ECCBoard 502491R00 12
ECCBoard 502496R01 12
ECCBoard 503652R01 12
ECCBoard 504147R00 12
ECCBoard 502266R00 C407 12
ECCBoard 502403R01 12
ECCBoard 502491R00 12
ECCBoard 503652R01 12
ECCBoard 502340R00 C408 12
ECCBoard 502498R00 12
ECCBoard 503652R01 12
ECCBoard 504149R00 12
ECCBoard 504155R00 12
ECCBoard 502498R00 C409 12
ECCBoard 502844R00 12
ECCBoard 504112R00 12
ECCBoard 504148R00 12
ECCBoard 504149R00 12
ECCBoard 502492R01 C410 12
ECCBoard 504111R00 12
ECCBoard 504150R00 12
ECCBoard 504152R00 12
ECCBoard 504153R00 12
ECCBoard 504154R00 12
ECCBoard 502340R00 C411 12
ECCBoard 502496R01 12
ECCBoard 503091R01 12
ECCBoard 504150R00 12
ECCBoard 504151R00 12
ECCBoard 504152R00 12
ECCBoard 504155R00 12
ECCBoard 502266R00 C412 12
ECCBoard 502495R01 12
ECCBoard 503652R01 12
ECCBoard 504111R00 12
