Connector Index
DRAWING # LOCATION Connector PINS
Electrical Information
inGrille 504153R00 C202 2
inGrille 504153R00 C203 2
inCeiling aboveAttendant Seat 504147R00 C206 2
underdash 504261R00 C208 2
inECC area 502403R01 C209 2
inECC area 502490R00 C212 2
at Floor Level 502498R00 C218 4
Front Console 502492R01 C310 12
Front Console 504111R00 12
Front Console 504150R00 12
Front Console 504152R00 12
Front Console 504153R00 12
Front Console 504154R00 12
Front Console 502340R00 C311 12
Front Console 502496R01 12
Front Console 503091R01 12
Front Console 504150R00 12
Front Console 504151R00 12
Front Console 504152R00 12
Front Console 504155R00 12
Front Console 502266R00 C312 12
Front Console 502495R01 12
Front Console 503652R01 12
Front Console 504111R00 12
Front Console 504152R00 12
Front Console 504154R00 12
Front Console 504151R00 C313 12
Front Console 504153R00 12
Front Console 504155R00 12
Front Console 502251R00 C314 12
Front Console 502393R01 12
Front Console 502492R01 12
Front Console 504151R00 12
Front Console 504155R00 12
Front Console 502266R00 C315 12
Front Console 502393R01 12
Front Console 502492R01 12
Front Console 504152R00 12
Front Console 504153R00 12
Front Console 504154R00 12
ECCBoard 502490R00 C400 12
ECCBoard 502844R00 12
ECCBoard 503091R01 12
ECCBoard 503652R01 12
ECCBoard 504147R00 12
ECCBoard 502266R00 C401 12
ECCBoard 502403R01 12
ECCBoard 502490R00 12
ECCBoard 502491R00 12
