STRYKER BATTERY
CHARGER INSTALATION
September 26,
2017
Page
1
of
1
AMBULANCE TYPE:
DEMERS 62800 - 62999
UNITS AFFECTED:
ALL UNITS EQUIPPED WITH THE STRYKER POWERPRO
STRETCHER
ACTION:
INSTALLATION OF THE STRYKER POWERPRO BATTERY CHARGER
LABOUR TIME:
.
3 HRS
BILL TO: BCAS
SERVICE PROCEDURE:
1. Remove the storage bins to provide space to
mount the Charger on the left of the lower shelf
located in the cabinet above the suction unit.
2. Position the mounting base ½ inch from the side
wall and ¾ inch from the front door track.
3. Using the charger base guide pins as a template,
drill two 3/16
th
holes through both the shelf and
the lower cabinet frame.
4. Squeeze two ¼” beads of silicone on to the base
and install on the shelf with the supplied machine
screws, lock washers and acorn nuts.
Tighten snug
but do not over tighten as damage to the shelving
unit will occur.
5. Insert the power cord and mount the charger
onto the base. Stick the double sided tape to the
transformer and attach to the wall behind the
charger. Secure the excess cables with zip ties.
Drill 3/16” holes here.
