Page 1 of 1
0107
Service Bulletin # 09-11
October 19, 2009
Questions or comments regarding this service bulletin may be directed to:
Erin Francis Phone 1-604-882-9333
BREAKER WIRE INSPECTION
Mandatory Optional Information Only
NewEra XC FleetMax Commander Legend 138 Legend 158 Classic Bus
Vehicles affected: 62725 through 62790
Please complete the requirements of this service bulletin within ..................... _______45____________
Part Cost n/a ........................................Labour Allowance included with accompanying bulletins.
Details
This intention of this bulletin is to confirm the correct routing of wires #58 (Thermo Power) and #154 (Right Bank
Cot Lights), each located in the ecc. There have been reported incidents of the #58 wires being attached to the
incorrect circuit breaker #10 which overloaded the breaker, causing it to trip. Please ensure that the #58 Thermo
Power wires are attached to the #8 circuit breaker, and the #154 Right Bank Cot Light wires are attached to the
#10 circuit breaker.
A portion of the 4 hours allocated for Bulletin 09-09 BCAS Isolator Installation has been set aside for this
inspection; any labour to inspect and or make adjustments will be part of and within this 4 hour allowance.
Thank you.
Fig 1 View of circuit breakers
#10 breaker. Confirm
#154 Right Cot Light
wires are attached
here.
#8 breaker. Confirm #54
Thermo Power wires
are attached here.
