Electrical Information
ECCBoardDrawing#
503134R00
Tuesday, October 31, 2006
Printed:
Note:Somewires are used for different applications than their description states. Therefore,
thewire numberwill take precedence over the descriptionwire. Somewiresdo not have
wire numbers. This is due to the use ofmanydifferent applications and not enough specific
wire labels to describe allof them.
Page 3-6a
RelayReferenceCodes
RELAY# DESCRIPTION
TYPE
Back-Up Alarm
1
87ANormallyClosed
Scene Lights -Rear
2
87NormallyOpen
Scene Lights - Left
3
87NormallyOpen
Scene Lights -Right
4
87NormallyOpen
Cot Lights - Left Low
5
87NormallyOpen
Cot Lights - LeftHigh
6
87ANormallyClosed
Cot Lights -Right Low
7
87NormallyOpen
Cot Lights -RightHigh
8
87ANormallyClosed
A/C Low
9
87NormallyOpen
A/CHigh
10
87NormallyOpen
Heater Low
11
87NormallyOpen
HeaterHigh
12
87NormallyOpen
LightBar
13
87NormallyOpen
LightBar
14
87NormallyOpen
Flasher
15
87NormallyOpen
Flasher
16
87NormallyOpen
Driving Lights
17
87NormallyOpen
Fog Lights
18
87NormallyOpen
PowerDoor Locks
19
87ANormallyClosed
PowerDoor Locks
20
87ANormallyClosed
Flasher/Scene
21
87ANormallyClosed
Flasher/Scene
22
87ANormallyClosed
Tachograph
23
87NormallyOpen
AmbulanceConnect
24
87DiodeNormallyOpen
Anti-Theft
40
87NormallyOpen
Anti-Theft
41
87NormallyOpen
Anti-Theft
42
87ANormallyClosed
Auto Throttle
43
87NormallyOpen
Indicator and Buzzer
44
87NormallyOpen
Back-Up Alarm
TDR1
60SecondDelay
AmbulanceConnect
TDR2
30SecondDelay
Circuit BreakerReferenceCodes
BREAKER#
DESCRIPTION
RATING
PowerWire#
Wigwag Power
1
10
107
Amps
22
FlasherPower
3
20
107
Amps
9
LeftAnd RightScene Light Power
4
25
107
Amps
14
SirenPower
5
20
107
Amps
13
Fog LightPower
7
15
107
Amps
18
ThermoPower
8
25
107
Amps
58
RightBankCot LightsPower
10
15
107
Amps
154
12VoltOutlet Power
12
10
107
Amps
70
OptionsPower
13
10
107
Amps
138
Power ExhaustVent Power
15
10
107
Amps
63
StrobePower
16
20
106
Amps
115
LightbarAnd FlasherSwitchPower
17
10
107
Amps
1
StrobePower
18
20
106
Amps
115
Laerdal PlugPower
19
10
107
Amps
71
RearScene Light Power
20
15
106
Amps
27
DoorAjarPower
21
10
107
Amps
73
AmbulanceConnectPower
22
10
106
Amps
36
MCCSpareSwitchPower
23
10
107
Amps
105
PowerDoor Lock
24
25
106
Amps
137
ConsoleSpareSwitchPower
25
10
107
Amps
104
Two-WayRadio
26
15
106
Amps
Red
Two-WayRadioPower
27
15
-
Amps
91
Electric SuctionPower
28
15
-
Amps
24
Two-WayRadioPower
29
15
-
Amps
91
LeftCot LightPower
30
15
-
Amps
54
IncubatorPlug APower
31
25
-
Amps
62
Option 1Power
32
10
-
Amps
40
Backlighting Lead
40
3
-
Amps
29
Clearance Lights Lead
41
3
-
Amps
72
ReverseSwitchPower
42
3
-
Amps
98
LeftSignal
45
3
-
Amps
120
RightSignal
46
3
-
Amps
121
Brake
47
5
-
Amps
122
Park/LicenseLamp
48
3
-
Amps
123
Option 1Power
49
5
-
Amps
40
FactoryBattery
50
10
-
Amps
25
IgnitionPower
51
10
-
Amps
90
ConnectorReferenceCodes
Description@ Location
Connector#
C202-LeftForewarn@ at Left ForewarnSpeaker
C203-RightForewarn@ atRight ForewarnSpeaker
C204-Heater FanMotor@ atHeater FanMotor
C205-A/C FanMotor@ atA/C FanMotor
C206-AudioAdjustSpeaker@ atSpeaker inCeiling aboveAttendantSe
C207-CabDome Light@ atDome Light inCabHeadliner
C208-ParkBrake Light@ atPark/Brake Lightunderdash
C209-Exhaust Fan@ atExhaustFan in ECC area
C210-ImpactSuctionUnit@ at ImpactSuctionUnit onRearConsole
C211-Intake Fan@ at Intake Fan in ECC area
C212-RicoSuctionPump@ atRicoSuctionPump in ECC area
C217-Exhaust Fan@ atSecond ExhaustFan in ECC
C218-Park/Signal Lights@ at Floor Level
C219-AudioAdjustSpeaker@ inCeiling atRear
C227-Thermostat@ -
C310-FrontConsole@ FrontConsole
C311-FrontConsole@ FrontConsole
C312-FrontConsole@ FrontConsole
C313-FrontConsole@ FrontConsole
C314-FrontConsole@ FrontConsole
C315-FrontConsole@ FrontConsole
C400-MCC@ ECCBoard
C401-MCC@ ECCBoard
C402-MCC@ ECCBoard
C403-MCC@ ECCBoard
C404-MainHarness@ ECCBoard
C405-MainHarness@ ECCBoard
C406-MainHarness@ ECCBoard
C407-MainHarness@ ECCBoard
C408-MainHarness@ ECCBoard
C409-MainHarness@ ECCBoard
C410-RearConsole@ ECCBoard
C411-RearConsole@ ECCBoard
C412-RearConsole@ ECCBoard
C413-RearConsole@ ECCBoard
C414-RearConsole@ ECCBoard
C415-RearConsole@ ECCBoard
C416-UnderChassis@ ECCBoard
C417-UnderChassis@ ECCBoard
C418-UnderDashHarness@ ECCBoard
C419-UnderDashHarness@ ECCBoard
C420-LightBar - Front@ ECCBoard
C421-B-Pillar@ ECCBoard
C422-ECCCompartment@ ECCBoard
C423-ECCCompartment@ ECCBoard
C424-DiodeBox@ ECCBoard
C425-DiodeBox@ ECCBoard
C426-CorneringModule@ ECCBoard
WireReferenceCodes
WireCode
Description
Gauge Color
Wire
WireCode
Description
Gauge Color
Wire
-
Blank
- -
Ground
14G Black
Ground
10G Black
Inverter Lead
14G Red
Light InCabArea
14G Red
SuctionPumpGround
14G Black
Two-WayRadio
10G Red
1 LTBSWPWR
LightbarAnd FlasherSwitchPower
14G Red
2 LTBRLY LD
LightbarRelay Lead
14G Green
3+ FOREWARN
Forewarn Lead
14G Brown
3- FOREWARN
Forewarn Lead
14G Brown
5+ SIRENSPRK
Siren Lead
14G Yellow
5- SIRENSPRK
Siren Lead
14G Yellow
7 FL LD
Flasher LeadGrouping7 (ASide)
14G Orang
7L LCOR LD
LeftCornering Lamp Lead
14G Orang
7A PRI FL LD
PrimaryModeFlashPattern Lead
14G Orang
7R RCOR LD
RightCornering Lamp Lead
14G Red
7B SEC FL LD
SecondaryMode FlashPattern Lead
14G Orang
8 FL LD
Flasher LeadGrouping8 (BSide)
14G Orang
8L LCOR LD
LeftWhiteCornering Lamp Lead
14G Orang
8A PRI FL LD
PrimaryModeFlashPattern Lead
14G Orang
8R RCOR LD
RightWhiteCornering Lamp Lead
14G Orang
8B SEC FL LD
SecondaryMode FlashPattern Lead
14G Orang
9 FL PWR
FlasherPower
12G Red
11 SEC FL RLY
FlasherSecondaryMode -Relay Lead
14G Orang
12 PRI FLRLY
FlasherPrimaryMode -Relay Lead
14G Orang
13 SNPWR
SirenPower
14G Red
14 SCENEPWR
LeftAndRightScene Light Power
14G Red
15 L SCENE
LeftScene Light Lead
14G White
16 RSCENE
RightSceneLight Lead
14G White
17 REARSCENE
RearScene Light Lead
14G White
18 FOG LTPWR
Fog LightPower
14G Red
19 FOG LT LD
Fog Light Lead
14G Brown
22 WIGWAGPWR
WigwagPower
14G Red
23 WIGWAG LD
Wigwag Flasher Lead
14G Brown
24 SUCT PWR
ElectricSuctionPower
14G Red
25 FACTBATT
Factory Battery
14G Red
26 DRAJAR LT
DoorAjar Light
14G Brown
27 SCENEPWR
RearScene LightPower
14G Red
28 DRAJARSW DoorAjar LightSwitch Lead
14G Blue
29 BACKLT LD
Backlighting Lead
14G Yellow
30
SpeakerWire
- Clear
32 THROT LD
Throttle Lead
14G Yellow
36 CONNPWR
AmbulanceConnect Power
14G Red
37 CONN LD
AmbulanceConnect Lead
14G White
40 OPT1 PWR
Option 1 Power
14G Red
41 OPT1 LD
Option 1 Lead
14G Blue
43 SUREST LD
Surestart Lead
14G White
50 THEFT LD
Anti-Theft Lead
14G White
51 CAB LT PWR
Cabinet Light Power
14G Red
52 CAB LT LD
Cabinet Light Lead
14G White
53 RCOTHIGH
RightBankCot LightHigh Lead
14G Blue
54 LCOTPWR
LeftCot Light Power
14G Red
55 LCOTHIGH
LeftBankCot LightHigh Lead
14G Blue
56 LCOT LOW LeftBankCot Light Low Lead
14G Yellow
57 SUCT LD
ElectricSuction Lead
14G Green
58 THERMOPWR
ThermoPower
14G Red
59 RCOT LOW RightBankCot Light Low Lead
14G Yellow
60 HTRMEDIUM
RearHeaterMedium Lead
10G Yellow
61 HTRHIGH
RearHeaterHigh Lead
10G Orang
62 INCBRPWR
IncubatorPlug A Power
14G Red
62B INCBRPWR
IncubatorPlug BPower
14G Red
63 EXHPWR
Power Exhaust VentPower
14G Red
64A EXHHIGH
Power Exhaust VentHighLead
14G Green
64B EXH LOW
Power Exhaust Vent Low Lead
14G Green
67 A/CMED
AirConditioning BlowerMedium
14G Orang
68 A/CHIGH
AirConditioning BlowerHigh
14G Green
70B 12VBOUTLET
12 VoltBOutletPower
12G Red
70 12VOUTLET
12 VoltOutletPower
12G Red
71 LAERDAL
LaerdalPlug Power
14G Red
72 CL LT LD
Clearance Lights Lead
14G Brown
73 DRAJARPWR DoorAjarPower
14G Red
74 HTRPWR
RearHeaterPower
14G Red
75 OPT2 PWR
Option 2 Power
14G Red
76 OPT2 LD
Option 2 Lead
14G Blue
77 A/CPWR
AirConditioning Power
14G Red
85 SN/HORN LD
Siren/HornSwitch Lead
14G Yellow
86 HORN LD
Horn Lead
14G Yellow
89 SN/HORNSIG LD SirenSignal Lead
14G White
90 IGNPWR
IgnitionPower
14G Brown
91 2-WAY PWR
Two-WayRadioPower
10G Red
95 BK-UPALM
Back-UpAlarm Lead
14G Brown
96 BK-UPDLY
Back-UpAlarmDelayPower
14G Red
98 RVSSWPWR
ReverseSwitchPower
14G Red
99 CORPWR
Cornering Lamp Relays Power
14G Red
100 MAP LTPWR
Map Light Power
14G Red
101 MAP LT LD
Map Light Lead
14G Yellow
102 AMMETER
AmmeterPower
14G Red
103 AMMETER LD
Ammeter Lead
14G Blue
104 CONSSPAREPWR ConsoleSpareSwitchPower
14G Red
105 MCCSPAREPWR MCCSpareSwitchPower
14G Red
106
ConversionBattery Live
- Red
107
AmbulanceConnect Live
- Red
108 INTAKEVENT LOW IntakeVent Low
14G Blue
109 INTAKEVENTHIGH IntakeVentHigh
14G Yellow
111 DRIVE LTS
Driving LightsControl
14G Yellow
112 DRIVE LTS
Driving LightsControl
14G Green
114 STROBEHIGH LOW StrobeHigh/Low
14G Purple
115 STROBEPOWER
StrobePower
14G Red-W
120 L SIGNAL
LeftSignal
14G Yellow
121 RSIGNAL
RightSignal
14G Blue
122 BRAKE
Brake
14G Green
123 PARK
Park/License Lamp
14G Brown
125 AUTEJECT
Auto Eject
14G Red
126 LOCKCTRL
Door LockControl
14G Blue
127 LOCKCTRL
Door LockControl
14G White
128 LOCK
Door Lock
14G Yellow
129 LOCK
Door Lock
14G Green
131 HRMETER
HourMeter
14G Yellow
133 CRIDEPWR
CrestrideControl Power
14G Red
134 CRIDE LD
CrestrideControl Lead
14G Yellow
135 OXYGENPWR
ElectricalOxygenPower
14G Red
136 OXYGEN LD
ElectricalOxygen Lead
14G Brown
137 DR LOCK LD
PowerDoor Lock
14G Red
138 OPTIONPWR
Options Power
14G Red
140 INVPWR
InverterPower
14G Red
141 FLUORESCE LIGHT Fluorescent Lights
14G Blue
142 L/BCONTRO
L/BControl
16G Orang
143 L/BCONTRO
L/BControl
16G Blue
144 L/BCONTRO
L/B Intensity
16G Green
145 CONVBATT
ConversionBattery Power
14G Red
154 RCOT PWR
RightBankCot Lights Power
14G Red
158 STROBE_C
StrobeControl
16G Green
160 OPTCON
OptionControl
14G Purple
