Connector Index
Schematic
LOCATION
Connector PIN
Electrical Information
Description
Title
inGrille
504153R01
C202
P01 Left Forewarn
BC 2010Carson SA-500 Siren Schematic
inGrille
504153R01
P02 Left Forewarn
BC 2010Carson SA-500 Siren Schematic
inGrille
504153R01
C203
P01 Right Forewarn
BC 2010Carson SA-500 Siren Schematic
inGrille
504153R01
P02 Right Forewarn
BC 2010Carson SA-500 Siren Schematic
inCeiling aboveAttendant Seat 504674R02
C206
P01 AudioAdjust Speaker
2010AudioAdjust Schematic
inCeiling aboveAttendant Seat 504674R02
P02 AudioAdjust Speaker
2010AudioAdjust Schematic
underdash
504692R04
C208
P01 ParkBrakeLight
2010ChevAuto-ThrottleSchematic
underdash
504692R04
P02 ParkBrakeLight
2010ChevAuto-ThrottleSchematic
Rear Passenger aboveKit Tree 504473R02
C209
P01 Exhaust Fan
2010 PowerVentilationExhaust Fan Schematic
Rear Passenger aboveKit Tree 504473R02
P02 Exhaust Fan
2010 PowerVentilationExhaust Fan Schematic
inECC area
502490R01
C212
P01 RicoSuction Pump
BC 2010RicoElectrical Suction Schematic
inECC area
502490R01
P02 RicoSuction Pump
BC 2010RicoElectrical Suction Schematic
inCeiling at Rear (Second)
504674R02
C219
P01 AudioAdjust Speaker
2010AudioAdjust Schematic
inCeiling at Rear (Second)
504674R02
P02 AudioAdjust Speaker
2010AudioAdjust Schematic
Under dash
504692R04
C234
P01 Dash buzzer
2010ChevAuto-ThrottleSchematic
Under dash
504692R04
P02 Dash buzzer
2010ChevAuto-ThrottleSchematic
Hidden inGrille
505169R00
C235
P01 Grill Switch
Custom 2010 PowerDoor LocksWithKey-less EntrySchematic
Hidden inGrille
505169R00
P02 Grill Switch
Custom 2010 PowerDoor LocksWithKey-less EntrySchematic
Cab
504251R00
C236
P01 Power Seat Base
Option 2 - Power Seat BaseSchematic
Cab
504251R00
P02 Power Seat Base
Option 2 - Power Seat BaseSchematic
Cab
504251R00
C237
P01 Power Seat Base
Option 2 - Power Seat BaseSchematic
Cab
504251R00
P02 Power Seat Base
Option 2 - Power Seat BaseSchematic
Box
504665R02
C249
P01 SceneLeft Front
2010 SideSceneLights Schematic
Box
504665R02
P02 SceneLeft Front
2010 SideSceneLights Schematic
Box
504665R02
C250
P01 SceneRight Front
2010 SideSceneLights Schematic
Box
504665R02
P02 SceneRight Front
2010 SideSceneLights Schematic
Box
504665R02
C253
P01 SceneLeft Rear
2010 SideSceneLights Schematic
Box
504665R02
P02 SceneLeft Rear
2010 SideSceneLights Schematic
Box
504665R02
C254
P01 SceneRight Rear
2010 SideSceneLights Schematic
Box
504665R02
P02 SceneRight Rear
2010 SideSceneLights Schematic
Proair 937
504944r00
C279
P01 Freezestat
BC 2010 Pro-Air 937Heat-ACComboSchematic
Proair 937
504944r00
P02 Freezestat
BC 2010 Pro-Air 937Heat-ACComboSchematic
Front Console
502492R02
C351
P01 Front Console
BC 2010 StrobeLight Schematic
Front Console
504150R01
Front Console
BC 2010Wig-WagSchematic
Front Console
504950R00
Front Console
BC 2010Anti-Theft Schematic
Front Console
504971R00
Front Console
BC 2010ChevConsoleWiringSchematic
Front Console
504962R00
P03 Front Console
BC 2010EmergencyLightingWhelenTomar LEDSchematic
Front Console
504971R00
Front Console
BC 2010ChevConsoleWiringSchematic
Front Console
504665R02
P04 Front Console
2010 SideSceneLights Schematic
Front Console
504971R00
Front Console
BC 2010ChevConsoleWiringSchematic
Front Console
504665R02
P05 Front Console
2010 SideSceneLights Schematic
Front Console
504971R00
Front Console
BC 2010ChevConsoleWiringSchematic
Front Console
504665R02
P06 Front Console
2010 SideSceneLights Schematic
Front Console
504971R00
Front Console
BC 2010ChevConsoleWiringSchematic
Front Console
504971R00
P07 Front Console
BC 2010ChevConsoleWiringSchematic
Front Console
505168R00
Front Console
Custom 2010Back-UpAlarmWithTimeDelayRelaySchematic
Front Console
504151r01
P08 Front Console
BC 2010HellaOptiluxFog/Driving-Light Schematic
Front Console
504971R00
Front Console
BC 2010ChevConsoleWiringSchematic
Front Console
504150R01
P10 Front Console
BC 2010Wig-WagSchematic
Front Console
504971R00
Front Console
BC 2010ChevConsoleWiringSchematic
Front Console
504971R00
P11 Front Console
BC 2010ChevConsoleWiringSchematic
Front Console
505168R00
Front Console
Custom 2010Back-UpAlarmWithTimeDelayRelaySchematic
Front Console
504685R02
P12 Front Console
2010ChevConsole andMCCBackLightingSchematic
Front Console
504971R00
Front Console
BC 2010ChevConsoleWiringSchematic
Front Console
504971R00
C352
P01 Front Console
BC 2010ChevConsoleWiringSchematic
Front Console
504971R00
P02 Front Console
BC 2010ChevConsoleWiringSchematic
Front Console
504950R00
P03 Front Console
BC 2010Anti-Theft Schematic
Front Console
504971R00
Front Console
BC 2010ChevConsoleWiringSchematic
Front Console
504670R03
P04 Front Console
2010Right Cot-Light Schematic
Front Console
504971R00
Front Console
BC 2010ChevConsoleWiringSchematic
Front Console
504944r00
P05 Front Console
BC 2010 Pro-Air 937Heat-ACComboSchematic
Front Console
504971R00
Front Console
BC 2010ChevConsoleWiringSchematic
Front Console
504944r00
P06 Front Console
BC 2010 Pro-Air 937Heat-ACComboSchematic
Front Console
504971R00
Front Console
BC 2010ChevConsoleWiringSchematic
Front Console
504944r00
P07 Front Console
BC 2010 Pro-Air 937Heat-ACComboSchematic
Front Console
504987r00
Front Console
BC 2010GMChassis Pick-Ups Schematic
Front Console
504971R00
P08 Front Console
BC 2010ChevConsoleWiringSchematic
Front Console
505168R00
Front Console
Custom 2010Back-UpAlarmWithTimeDelayRelaySchematic
Front Console
504971R00
P09 Front Console
BC 2010ChevConsoleWiringSchematic
Front Console
505168R00
Front Console
Custom 2010Back-UpAlarmWithTimeDelayRelaySchematic
Crestline
Coach
Wednesday,March 17, 2010
Vehicle
Manual
Page 3-48
