ORDERING INFORMATION
SPECIFICATIONS
Model No.
Description
Voltage
780–1228
4Output NEOBE
®
MultipleFlash 12 thru 28VDC
Power Supply, dual intensity.
Head control circuitry allows
activating of either set of 2 heads or
all 4 lamps at the same time.
780–1228–WP Same as above except with
waterproof lamp, control and
power connectors. Requires
WP lamp cables.
Accessories
PHOTO–02 Photocell Kit
770–SW
DemoControl Box, includesCigar Plug,
6' Control Cable, FourModeSwitches, andPhotocell.
LampCables for:
780–1228 & 780–1228–WP
see pg. D4
Power Requirements:
6.0Aavg.@ 12VDC
3.0Aavg.@ 24VDC
Output Power Rating:
65Wattsminimum inHi-Intensity,
NEOBE flash rate, 2 groups running
FlashRate:
60MFPM/Head-NEOBE rateminimum
100MFPM/Head-HYPER-NEOBE rateminimum
FlashPattern:
5 equal power flashes/multi-flash
Control Features:
On-Off and all features are controlled by switching positive
low current battery voltage.
Themain battery powermay be left connected to the
supply at all times. Current draw is less than 100
microamps in standby.
Construction:
Glass filled Lexan
®
case, polyurethane potting.
Size:
Weight:
7.125" x 3.75" x 2.50"
3.5 lbs.
(181mm)
(95mm)
(64mm)
(1.56 kg.)
TOMAR introduces NEOBE
®
a revolutionary new lighting technology. TOMAR model 780–1228 NEOBE
®
power
supply features a technology that produces the look of neon and the intensity of strobe lighting, combined into one
lamp that appears to burn continuously rather than flash. TheNEOBE
®
design producesmore light per watt than any
strobe power supply on the market. The result is unequalled warning light performance, far superior to a halogen,
rotator, or conventional strobe. TOMARmodel 780–1228 NEOBE
®
power supply is designed to operate one to four
remote strobeheads inamultiple flashalternatingpattern. Theunit featuresweatherproof designandhi-low intensity,
whichmay be selectedmanually by a remote switch or automatically by remotemounted photocell. The 780–1228
operates on 12 thru 28VDC, features head cut-out circuitry to disable sets of heads, polarity protection diode, and
contains RFI filters for both high and low band. The TOMARNEOBE
®
power supply features a revolutionary strobe
circuit that extends the dwell time (on time) of the strobe as well as increasing the life of the strobe lamp by
approximately 50%.AnyTOMAR remote strobe light headwill operatewith themodel 780–1228 power supply.
EXTENDED 10YEARWARRANTY!
This product is covered byTOMAR’s standardwarranty (see back cover) except thewarranty period is extended to 10 years.
THE LOOKOFNEON
WITHTHEPOWEROFSTROBE
780–1228
NEOBE
®
Power Supply
770–SW
780–1228–WP
Water Proof
NEOBE
®
Power Supply
780–1228NEOBE
®
POWERSUPPLY
Potted for HighDurability
2100WESTOBISPO
GILBERT, AZ. 85233
PHONE: 800–338–3133
FAX:
800–688–6627
®
